KEXINT GJDFBH Indoor Flat Ribbon Fiber Optic Cable 2-12 Cores SM MM

Name: KEXINT GJDFBH Indoor Flat Ribbon Fiber Optic Cable 212 Cores SM MM
Brand: KEXINT
Price: 184.35 USD

China KEXINT GJDFBH Indoor Flat Ribbon Fiber Optic Cable 2-12 Cores SM MM wholesale

Brand Name : KEXINT

Model Number : GJDFBH

Certification : CE Iso-9001 Ross UL

Place of Origin : CHINA

MOQ : 1+km

Price : 184.35+$+km

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram

Supply Ability : 1000+KM+Day

Delivery Time : 10

Packaging Details : box

Color : Yellow...optional

Outsheath : PE,LSZH,PVC

Fiber count : 1-12 Cores

Fiber Type : SM/MM

Strength Member : Aramid Yarn

Application : Indoor

Storage temperature : -60~+80℃

Contact Now

KEXINT 2-12 Cores SM MM GJDFBH Indoor Flat Ribbon Fiber Optic Cable

Indoor optical cables are optical cables laid in buildings and are mainly used for communication equipment, computers, switches and end-user equipment in buildings. in order to convey information.

Fiber:Up to12.
Fiber Types: Single-mode or multimode
Cable Types: Ribbon fiber
Strength Member: Aramid yarn
Sheath Options: Single LSZH/PVC sheath
Operating Temperature:-20C~+70C
Compliances: In Accordance with IEC, ITU and EIA standards

Features:
High fiber density, small size, light weight, good looking and compact structure; .
Easy for installation and spicing, branching and flame retardant;
All dielectric structure design, without electromagnetic induction effect. High-strength aramid fiber reinforcements ensure that the optical fiber has no tensile strain and ensure long-term stability of optical fiber transmission characteristics;
Tight-buffered optical cables can be directly connected without transition joint boxes and pigtails, which is very suitable for construction operations and easy maintenance.

Applications:
Indoor cabling; Ribbon patch cord and ribbon pigtail;
As flexible connection cable between equipments.


Technical Specification:

Cable type	Fibercounts	Cable dimension (mm)	Tensile Strength(N)		Crush Resistance( N/10omm)		Minimum bend radius(mm)
Cable type	Fibercounts	Cable dimension (mm)	Short term	Long term	Short term	Long term	Dynamic	static
GJDFH(V)	4	2.2×3.2	220	100	500	250	30H	15H
GJDFH(V)	6	2.2x4.2	220	100	500	250	30H	15H
GJDFH(V)	8	2.2x4.2	220	100	500	250	30H	15H
GJDFH(V)	12	2.2x4.7	220	100	500	250	30H	15H
